Description
Suitable for the Suzuki models listed below. Rated up to 50A/500 watt, for permanent magnet generators. Most are around 25-35A, so this is a super heavy-duty regulator.
Dimensions:
Width: 80 mm
Length: 100 mm
Height: 30 mm
Wires length: 260 mm, 250 mm
Fixing holes center to center: 80 mm
Fits Models
- Suzuki GSXR750 2006 – 2019
- Suzuki GSXR600 2006 – 2019
- Suzuki Boulevard C50 VL800 2005 – 2019
- Suzuki Boulevard M50 VZ800 2005 – 2019
- Suzuki Boulevard C50T VL800T 2004 – 2019
- Suzuki SV650 2017 – 2019
- Suzuki V-Strom 650 2008 – 2019
- Suzuki GSF1250 Bandit 2007 – 2016
- Suzuki GSXR1000 2005 – 2016
- Suzuki GSXS750 2015 – 2016
- Suzuki SFV650 Gladius 2009 – 2015
- Suzuki Hayabusa GSX1300 R 2008 – 2012
- Suzuki GSX1250 2011
- Suzuki GSX1300 B-King 2008 – 2009
- Suzuki GSX650 F 2008 – 2009
- Suzuki Boulevard C90 VL1500 2005 – 2009
- Suzuki Boulevard C90T VL1500T 2005 – 2009
- Suzuki LTA700 X KingQuad 2005 – 2007
- Suzuki VL800 Volusia 2001 – 2005
Note: Unsuitable for use with lithium batteries. Using the incorrect battery type will void all warranty and may seriously damage your motorcycle’s charging system.
